QUALITY MANUFACTURE HIGH PRECISION ER 32 COLLET/ER11 /ER16/ER20/ER25/ER40

Model: ER collet ER32 0.01mm
Place of Origin: Zhejiang,China (Mainland)
Model No:: ER32-A
Material: SUJ2
HRC: 44-48
Surface roughness: RZ2.5
Heat treatment: Vaccum heat treatment
Precision: ≤0.01mm
Brand Name: ZENTAX
Avaiable Service: OEM ,ODM
Certification: ISO9001:2008

inquiry

basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:5.9 USDProduction Capacity:50000 pieces/month
Trade Term:FOBPacking:carton box
Payment Terms:T/T, PaypalDelivery Date:1-2month
Min. Order:10 Piece/Pieces
Means of Transport:Ocean, Air

1.Professional Experience

2.ISO9001: 2008

3.OEM & ODM Service
4.Safe Packing, Prompt Delivery





SPECIFICATION
1Model NoER32-A
2MaterialSUJ2
3Hardness44°-48°
4Surface RoughnessRZ2.5
5Precision≤0.01mm
6Heat TreatmentVaccum Heat
7Available serviceOEM,ODM
8CertificationISO9001:2008

·The internal hole is manufactured by precise honing

·The concentricity is totally examined according to DIN norm.There are two classes of precision :general  A class 0.01mm and UP class 0.005mm

·It is used for the cutting tools like drills,taps ,mills and reamers ,etc.




ER8
ER11
ER16
CODE SIZECODE SIZECODE SIZE
ER8-1.01.0-0.5ER11-1.01.0-0.5ER16-1.01.0-0.5
ER8-1.51.5-1.0ER11-1.51.5-1.0ER16-1.51.5-1.0
ER8-2.02.0-1.5ER11-2.02.0-1.5ER16-2.02.0-1.5
ER8-2.52.5-2.0ER11-2.52.5-2.0ER16-2.52.5-2.0
ER8-3.03.0-2.5ER11-3.03.0-2.5ER16-3.03.0-2.0
ER8-3.53.5-3.0ER11-3.53.5-3.0ER16-4.04.0-3.0
ER8-4.04.0-3.5ER11-4.04.0-3.5ER16-5.05.0-4.0
ER8-5.05.0-4.5ER11-4.54.5-4.0ER16-6.06.0-5.0

ER11-5.05.0-4.5ER16-7.07.0-6.0
ER11-5.55.5-5.0ER16-8.08.0-7.0
ER20 ER11-6.06.0-5.5ER16-9.09.0-8.0
CODE SIZEER11-6.56.5-6.0ER16-10.010.0-9.0
ER11-7.07.0-6.5
ER20-2.02.0-1.5
ER32
ER20-2.52.5-2.0ER25 CODESIZE
ER20-3.03.0-2.0CODE SIZE
ER20-4.04.0-3.0ER32-3.03.0-2.0
ER20-5.05.0-4.0ER25-2.02.0-1.5ER32-4.04.0-3.0
ER20-6.06.0-5.0ER25-3.03.0-2.0ER32-5.05.0-4.0
ER20-7.07.0-6.0ER25-4.04.0-3.0ER32-6.06.0-5.0
ER20-8.08.0-7.0ER25-5.05.0-4.0ER32-7.07.0-6.0
ER20-9.09.0-8.0ER25-6.06.0-5.0ER32-8.08.0-7.0
ER20-10.010.0-9.0ER25-7.07.0-6.0ER32-9.09.0-8.0
ER20-11.011.0-10.0ER25-8.08.0-7.0ER32-10.010.0-9.0
ER20-12.012.0-11.0ER25-9.09.0-8.0ER32-11.011.0-10.0
ER20-13.013.0-12.0ER25-10.010.0-9.0ER32-12.012.0-11.0

ER25-11.011.0-10.0ER32-13.013.0-12.0
ER40 ER25-12.012.0-11.0ER32-14.014.0-13.0
CODE SIZEER25-13.013.0-12.0ER32-15.015.0-14.0
ER25-14.014.0-13.0ER32-16.016.0-15.0
ER40-3.03.0-2.0ER25-15.015.0-14.0ER32-17.017.0-16.0
ER40-4.04.0-3.0ER25-16.016.0-15.0ER32-18.018.0-17.0
ER40-5.05.0-4.0
ER32-19.019.0-18.0
ER40-6.06.0-5.0ER32-20.020.0-19.0
ER40-7.07.0-6.0
ER40-8.08.0-7.0
ER40-9.09.0-8.0
ER40-10.010.0-9.0
ER40-11.011.0-10.0
ER40-12.012.0-11.0
ER40-13.013.0-12.0
ER40-14.014.0-13.0
ER40-15.015.0-14.0
ER40-16.016.0-15.0
ER40-17.017.0-16.0
ER40-18.018.0-17.0
ER40-19.019.0-18.0
ER40-20.020.0-19.0
ER40-21.021.0-20.0
ER40-22.022.0-21.0
ER40-23.023.0-22.0
ER40-24.024.0-23.0
ER40-25.025.0-24.0
ER40-26.026.0-25.0



Some Processings

Certification

Packages

Relative Products

Company Information

Zhejiang Yinqiu Machinery Co., Ltd. was founded in 2003,which is a comprehensive technology-based enterprise mainly engaged in manufacturing of intelligent equipment and precision machine tools.

Our company has the production area with over 16,000 square meters, workshops with an area of 15,000 square meters and three production and processing centers—the precision machine tool and cutting tool machining center, sheet metal parts workshop, intelligent machine assembly workshop.

Meanwhile, our company is AAA-level Credit Enterprise by the Ministry of Commerce.

Precision machine tools department mainly manufacture series of precision machine tooling system:CNC high speed tool holder,pull studs,ER series,SK series collets,straight collets,tapping collets,etc.We imported key processing and inspectionequipment .We always keep improving,manufacture every product as an art.Every product will be 100% tested before delivery,Our product conform to the tooling system of Germany,Japan.

Guided by the management concept of "Market-oriented, Guarantee by Quality, Development by Innovation", our company provides users with the most advanced technology and products and excellent service.
